ELECTRICAL - Lights, Exterior
| Part Number | Description | Price | Add | |
|---|---|---|---|---|
EXL1.0  |
TURN SIGNAL ASSEMBLY , FRONT , BEEHIVE DESIGN 644-631-009-00 Fits 356 Pre A starting in 1954-55 and up to late 57. |
NLA-631-009-00 | $55.00 |  |
EXL1.2 |
LENS , WHITE , BEEHIVE DESIGN , 2 Required. 644-631-009-01 Fits early 1957 T1 models. |
NLA-631-009-01 | $32.00 | |
| EXL1.3 |
SCREW MACHINE , BEZEL , SLOTTED , STAINLESS STEEL 4mm X 12mm , 2 Required NLA-631-4X1-2 Used on Early 356 to Early T1 356 front turn signals. |
NLA-631-4X1-2 | $0.82 | |
| EXL1.4 |
Screw, Bezel - Stainless. 4x12 PHILLIPS. 2 Req'ed per lens. Used on late T1- 59T2 front turn signals. |
NLA-631-010-00 | $0.45 | |
| EXL2.0 |
LIGHT ASSEMBLY , TUN SIGNAL , FRONT , FROSTED WHITE , EUROPEAN DESING LEFT and RIGHT WEDGE STYLE , INCLUDES LENS , NON WEDGE BASE NLA-631-009-00 Fits 356AT2 |
NLA-631-009-00 | $57.75 | |
| EXL2.1 |
LENS , TURN SIGNAL , CLEAR , Fits FRONT WEDGE TYPE ONLY , 40mm HIGH NLA-631-004-01 Fits 356AT2. |
NLA-631-004-01 | $27.40 | |
| EXL3.0 |
TURN SIGNAL ASSEMBLY , FRONT LEFT , CLEAR LENS NLA-631-401-05 Fits 356B & C. |
NLA-631-401-05 | $146.10 | |
| EXL3.1 |
TURN SIGNAL ASSEMBLY , FRONT RIGHT , CLEAR LENS NLA-631-402-05 Fits 356B & C. |
NLA-631-402-05 | $155.25 | |
| EXL3.2 |
TURN SIGNAL ASSEMBLY , FRONT LEFT , AMBER LENS NLA-631-401-10 Fits 356B & C. |
NLA-631-401-10 | $155.25 | |
| EXL3.3 |
TURN SIGNAL ASSEMBLY , FRONT RIGHT , AMBER LENS NLA-631-402-10 Fits 356B & C. |
NLA-631-402-10 | $155.25 | |
| EXL3.4 |
LENS , TURN SIGNAL , FRONT , CLEAR NLA-631-411-01 Fits 356B & C. |
NLA-631-411-01 | $27.40 | |
| EXL3.5 |
LENS , TURN SIGNAL , FRONT , AMBER NLA-631-411-06 Fits 356B & C. |
NLA-631-411-06 | $27.40 | |
| EXL3.6 |
GASKET RUBBER , to SEAL LENS , LIGHT GRAY , 2 Required NLA-631-413-01 Fits 356B & C. |
NLA-631-413-01 | $5.05 | |
| EXL3.7 |
SEAL RUBBER BOOT , BLACK , Fits INSIDE LIGHT ASSEMBLY NLA-631-415-06 Fits 356B & C. |
NLA-631-415-06 | $12.90 | |
| EXL3.8 |
PLASTIC PROFILE PIECE , BETWEEN LIGHT ASSEMBLY and FENDER 644-631-495-05 Fits 356B & C. |
644-631-495-05 | $3.75 | |
| EXL4.1 |
HEADLIGHT RIM , CHROME , with ADJUSTMENT SCREWS at 4 O"CLOCK and 8 O"CLOCK NLA-62-015 Fits all 356 Models. |
NLA-62-015 | $50.25 | |
| EXL4.3 |
SCREW and SPACER . SECURES HEADLIGHT ASSEMBLY to FENDER NLA-631-112-00 Fits all 356 Models. |
NLA-631-112-00 | $15.30 | |
| EXL6.0 |
RETAINING SPRING , SECURES HEADLIGHT GLASS to HEADLIGHT ASSEMBLY for U.S.A. SEALED BEAM BULBS , 14 Required 644-631-122-31 Fits all 356 Models. |
644-631-122-31 | $4.50 | |
| EXL7.0 |
SEAL RUBBER , GRAY , for AROUND HEADLIGHT ASSEMBLY GLASS 644-631-114-00 Fits all 356 Models. |
644-631-114-00 | $4.00 | |
| EXL8.0 |
HEADLIGHT ASSEMBLY , COMPLETE , with ADJUSTMENT SCREWS at 4 O"CLOCK and 8 O"CLOCK NLA-62-015 Fits all 356 Models. Typically seen on 356A up to the T5 model. |
NLA-62-015 | $50.25 | |
| EXL8.1 |
HEADLIGHT ASSEMBLY , COMPLETE , with ADJUSTMENT SCREWS at 1 O"CLOCK and 7 O"CLOCK NLA-62-014 Fits all 356 Models. Typically seen on 356T6B up to the 356C model. |
NLA-62-014 | $162.00 | |
| EXL8.2 |
HEADLIGHT ASSEMBLY , COMPLETE , HELLA EUROPEAN DESIGN 644-631-101-01 Fits all 356 Models. |
644-631-101-01 | $274.00 | |
| EXL8.5 |
BUCKET , HEADLIGHT ASSEMBLY , BLACK , NO TABS INSIDE , 2 Required PORSCHE O.E.M. COMPONENT , Fits 356 A , 356 B , and 356 C 644-631-151-00-GRV |
644-631-151-00-GRV | $ | |
| EXL8.6 |
BUCKET , HEADLIGHT ASSEMBLY , BLACK , NO TABS INSIDE , 2 Required QUALITY REPRODUCTION , Fits 356 A , 356 B , and 356 C NLA-631-151-10 |
NLA-631-151-10 | $ | |
| EXL9.0 |
BULB for HEADLIGHT , 6volt , REPLACEMENT SEALED BEAM , 7" DIAMETER 50 watt / 45 watt , for U.S.A. ASSEMBLY 644-631-106-31 |
644-631-106-31 | $31.75 | |
| EXL9.1 |
BULB for HEADLIGHT , 12volt , REPLACEMENT SEALED BEAM , 7" DIAMETER 60 watt / 40 watt , for U.S.A. ASSEMBLY 999-631-108-90 Replacement headlight bulb for earlier Porsches using 12 VOLT systems. |
999-631-108-90 | $31.75 | |
| EXL10.0 |
HALOGEN BULB HEADLIGHT CONVERSION ASSEMBLY , 12volt , from ORIGINAL HELLA HEADLIGHT CUSTOMER MUST SUPPLY H4 TYPE BULB , 60 watt / 55 watt WAP-945-002-00 Consult bulb section |
WAP-945-002-00 | $60.50 | |
| EXL10.3 |
BULB for HEADLIGHT ASSEMBLY , HALOGEN Type H4 , 60 watt / 55 watt 900-631-201-90 |
900-631-201-90 | $6.40 | |
| EXL11.0 |
HEADLIGHT ASSEMBLY , EUROPEAN DESIGN , HELLA Manufactured 644-631-101-01 Fits all 356 Models. |
644-631-101-01 | $274.00 | |
| EXL11.1 |
LENS GLASS , ORIGINAL DESIGN , CLEAR GLASS LENS HELLA Manufactured 644-631-111-31 Fits all 356 Models. |
NLA-631-111-31 | $91.35 | |
| EXL11.2 |
LENS GLASS , ORIGINAL DESIGN , FLUTED GLASS LENS HELLA Manufactured 644-631-111-00 Fits all 356. |
644-631-111-00 | $91.35 | |
| EXL12.0 |
CONNECTOR SPECIAL , 3 PRONG FEMALE for PAR 36 6volt and 12volt SEALED BEAM HEADLIGHT BULBE SIC-900-613-00 Fits all 356 Models. |
SIC-900-613-00 | $4.10 | |
| EXL13.0 |
TAIL LIGHT ASSEMBLY , REAR , RED , BEEHIVE DESIGN , 4 Required 644-631-008-00 Fits 356, 356A up to Coupe #100000, Cab #61700 & Speedster #83200. |
NLA-631-008-00 | $57.55 | |
| EXL13.2 |
TAIL LIGHT LENS , REAR , RED , BEEHIVE DESIGN , 4 Required 644-631-008-01 Fits early 356A. |
NLA-631-008-01 | $27.40 | |
| EXL13.3 |
GASKET RUBBER SEAL , for BEEHIVE DESIGN TAIL LIGHT LENS 356-62-223 Fits 356, 356A. |
356-62-223 | $7.20 | |
| EXL13.4 |
MACHINE SCREW , for RETAINING BEEHIVE DESIGNED LENS BEZEL , 2 Required Per LIGHT 644-631-010-00 Fits 356, 356A (pre T2). |
NLA-631-010-00 | $0.45 | |
| EXL13.5 |
GASKET FLAT THICK , for BEEHIVE DESIGN LENS NLA-631-008-02 |
NLA-631-008-02 | $15.00 | |
| EXL14.0 |
LIGHT ASSEMBLY , TAIL LIGHT , TEARDROP DESIGN , REAR LEFT , RED ONLY U.S.A. VERSION TAIL LIGHT ASSEMBLY 644-631-403-00 Fits 356A, B & C. |
644-631-403-00 | $97.50 | |
| EXL14.1 |
LIGHT ASSEMBLY , TAIL LIGHT , TEARDROP DESIGN , REAR RIGHT , RED ONLY U.S.A. VERSION TAIL LIGHT ASSEMBLY 644-631-404-00 Fits 356A, B & C. |
644-631-404-00 | $97.50 | |
| EXL14.2 |
LIGHT ASSEMBLY , TAIL LIGHT , TEARDROP DESIGN , REAR LEFT , AMBER and RED EUROPEAN VERSION TAIL LIGHT ASSEMBLY 644-631-403-10 Fits 356A, B & C. |
644-631-403-10 | $91.50 | |
| EXL14.3 |
LIGHT ASSEMBLY , TAIL LIGHT , TEARDROP DESIGN , REAR RIGHT , AMBER and RED EUROPEAN VERSION TAIL LIGHT ASSEMBLY 644-631-404-10 Fits 356A, B & C. |
644-631-404-10 | $91.50 | |
| EXL14.4 |
LENS ONLY , TAIL LIGHT , TEARDROP DESIGN , REAR LEFT , RED ONLY U.S.A. VERSION TAIL LIGHT ASSEMBLY 644-631-421-00 Fits 356A, B & C. |
644-631-421-00 | $32.50 | |
| EXL14.5 |
LENS ONLY , TAIL LIGHT , TEARDROP DESIGN , REAR RIGHT , RED ONLY U.S.A. VERSION TAIL LIGHT ASSEMBLY 644-631-422-00 Fits 356A, B & C. |
644-631-422-00 | $31.50 | |
| EXL14.6 |
LENS ONLY , TAIL LIGHT , TEARDROP DESIGN , REAR RIGHT , AMBER and RED TEARDROP DESIGN , EUROPEAN VERSION TAIL LIGHT ASSEMBLY 644-631-421-10 Fits 356A, B & C. |
644-631-421-10 | $23.50 | |
| EXL14.7 |
LENS ONLY , TAIL LIGHT , TEARDROP DESIGN , REAR RIGHT , AMBER and RED TEARDROP DESIGN , EUROPEAN VERSION TAIL LIGHT ASSEMBLY 644-631-422-10 Fits 356A, B & C. |
644-631-422-10 | $23.50 | |
| EXL14.8 |
GASKET RUBBER BASE for MOUNTING ONR TEARDROP TAIL LIGHT ASSEMBLY 644-631-491-01 Fits 356A, B & C. |
644-631-491-01 | $19.25 | |
| EXL14.9 |
TERMINAL RUBBER BOOT PROTECTS EACH of 2 WIRES to ONE TAIL LIGHT ASSEMBLY , 2 Required PER LIGHT 644-631-419-00 Fits 356A, B & C. |
644-631-419-00 | $8.75 | |
| EXL14.10 |
REINFORCING PLASTIC FRAME SUPPORTS THE TEARDROP TAIL LIGHT ASSEMBLY LENS 644-631-451-00 Fits 356A, B & C. |
NLA-631-451-00 | $21.95 | |
| EXL14.11 |
MACHINE SCREW , SECURES TEAR DROP TAIL LIGHT ASSEMBLY To VEHICLE , 2 Required PER LIGHT 966-A2 Fits 356A, B & C. |
966-A2 | $0.50 | |
| EXL15.0 |
LIGHT ASSEMBLY for LICENSE PLATE SHINES DOWNWARD , COMPLETE ASSEMBLY , EARLIEST VEHICLES 644-631-005-00 Used up until the following VIN numbers Coupe 100001 Cab 61701 Speedster 83201. |
NLA-631-005-00 | $365.25 | |
| EXL15.1 |
LIGHT ASSEMBLY for LICENSE PLATE SHINES UPWARD , COMPLETE ASSEMBLY , LATER EARLY VEHICLES 644-631-005-00 Late 356A from 100001 Coupe, 61701 Cabrio, & 83201 Speedster. |
NLA-631-601-00 | $251.10 | |
| EXL15.2 |
RUBBER BASE , for MOUNTING ONE LICENSE PLATE LIGHT ASSEMBLY for USE ON EARLIEST VEHICLES 644-007-931-00 Fits 356, 356A. |
644-007-931-00 | $39.00 | |
| EXL16.0 |
LIGHT ASSEMBLY for REVERSE MOVEMENT QUALITY REPRODUCTION , Includes BASE MOUNTING GASKET 644-631-631-05 Fits 356B & C. |
644-631-631-05 | $96.00 | |
| EXL16.2 |
MOUNTING GASKET BASE and BEZEL , for REVERSE LIGHT ASSEMBLY QUALITY REPRODUCTION , Includes BASE MOUNTING GASKET , and BULB 644-631-631-06 Fits 356B & C. |
644-631-631-06 | $26.50 | |
| EXL16.3 |
GASKET RUBBER , for REVERSE / BACK UP LIGHT ASSEMBLY LENS 644-631-644-05 Fits 356B & C. |
644-631-644-05 | $8.75 | |
| EXL17.0 |
LIGHT ASSEMBLY for LICENSE PLATE , COMPLETE 644-631-631-05 Fits 356B & C. |
644-631-601-05 | $91.50 | |
| EXL17.3 |
GASKET RUBBER , for LICENSE PLATE LIGHT ASSEMBLY BASE 644-631-615-05 Fits 356B & C. |
644-631-615-05 | $7.25 | |
| EXL17.4 |
GASKET RUBBER , for LICENSE PLATE LIGHT ASSEMBLY LENS 644-631-614-05 Fits 356B & C. |
644-631-614-05 | $4.75 | |
| EXL18.0 |
REFLECTOR , COMPLETE , 6mm M6 STUDS INCLUDES ALUMINUM ANGLE BASE SPACERS 644-731-501-00 Fits 356, 356A. |
644-731-501-00 | $38.50 | |
| EXL18.1 |
ALUMINUM ANGLE BASE SPACER , for REFLECTOR ASSEMBLY ONLY MOUNT ANGLE SIDE AGAINST VEHICLE BODY , 2 Required 644-731-501-11 Fits 356, 356A. |
NLA-731-501-11 | $5.25 | |
| EXL18.2 |
RUBBER WASHER , BLACK , for REFLECTOR ASSEMBLY ONLY , 2 Required 644-731-501-12 Fits between the aluminum base pieces on 356B & C reflectors. |
NLA-731-501-12 | $0.55 | |
| EXL18.5 |
SCREW PLUG , SLOTTED , CHROME INCLUDES WAVE LOCK WASHER and HEX NUT 644-025-120-00 For reflector hole below the bumper found on USA 356 B/C Roadster, Cab & Coupe. |
NLA-025-120-00 | $15.10 | |
| EXL18.6 |
RUBBER PLUG , 2 Required 644-025-120-20 Used for plugging the hole under the bumper for the Euro reflector not found on USA cars. |
NLA-025-120-20 | $4.80 | |
| EXL19.0 |
REFLECTOR PIECE , in CHROME HOLDING PIECE with M6 6mm STUD , 2 Required U.S.A. DEGIN REFLECTOR 644-731-501-10 Fits 356B & C. |
644-731-501-10 | $36.75 | |
| EXL19.1 |
REFLECTOR PIECES , CHROME MOUNT to VEHICLE REAR on SIDE OF REFLECTOR ASSEMBLY , SOLD IN PAIRS 644-731-507-00 Fits 356B & C. |
NLA-731-507-00 | $41.10 | |
| EXL19.2 |
GASKET SEAL BASE , RUBBER , for REFLECTOR ASSEMBLY BASE BETWEEN ANGLE SPACER ANGLE SIDE and VEHICLE BODY , 2 Required 644-731-517-05 644-731-517-05 Fits 356B & C. |
NLA-731-517-05 | $6.20 | |
| EXL19.3 |
LOCKING SPECIAL HEX NUT , CHROME , USED to SECURE REFLECTOR ASSEMBLY to VEHICLE BODY ( INSIDE BODY CAVITY ) , 2 Required 644-731-515-05 Fits 356B & C. |
644-731-515-05 | $14.75 | |
Prices and availability subject to change without notice.
